Cel-Fi Low-Profile Ceiling Antenna 698-4000mhz 2/5dBi Antenna - 150dBc PIM; N Female
The Blackhawk 4G-5G Low-Profile Ceiling Antenna, 698 to 4000 MHz offers exceptional performance for both 4G and 5G networks. This high-gain antenna is ideal for enhancing signal strength within a range of residential, commercial, and industrial mobile broadband applications on any mobile network.
This is the ideal indoor antenna for Cel-Fi repeater systems. Indoor low-profile antennas are designed to be mounted to the ceiling of your building to provide consistently distributed mobile phone service from your Cel-Fi repeater/booster. The antenna is compact with a visually unobtrusive design similar to a smoke alarm.
The Blackhawk Low-Profile Ceiling Antenna will provide the perfect solution for voice and data applications. Perfect for repeater applications that require a 360° beamwidth for complete internal coverage.
Features:
- 700 MHz to 4000 MHz Frequency Range
- Linear Horizontal Polarisation
- < -150 dBc Passive Intermodulation (PIM)
- Compact Design
- Supports up to 50W
- Delivers consistent peak gain across different frequencies:
Specifications:
| Category | Specification | Details |
|---|---|---|
| Model Number | HCEI-6940-3.N2 | Powertec 4G-5G Slim Series Ceiling Antenna |
| Order Code | ANT-BH-00010 | Product Order Code |
| Frequency Range | 698-4000 MHz | Supports 4G LTE, 5G NR bands |
| Polarisation | Linear, Horizontal | For improved isolation |
| Peak Gain | 3-5 dBi | Gain varies across frequency bands |
| VSWR | <1.8:1 / <2.0:1 | Varies with frequency range |
| Input Impedance | 50 Ω | Standard impedance for cellular antennas |
| Maximum Power | 50 W | Max input power handling capacity |
| PIM (3rd Order) | <-150 dBc | Low Passive Intermodulation for enhanced signal quality |
| Dimensions | 190 × 190 × 7.3 mm | Compact, low-profile design |
| Weight | 0.25 kg | Lightweight construction |
| Connector Type | N Female | Standard connector for high-performance RF |
| Radome Material | ABS Plastic | UV-stabilised for durability |
| Operating Temperature | -40 °C to +65 °C | Designed for indoor use across wide temperature ranges |
| Mounting | Ceiling Mount | For internal building applications |
